SQM-0.4L Small Type Planetary Ball Mill Machine
Samy
SQM-0.4L
| 100ml Stainless steel grinding jars: | |
|---|---|
| Quantity: | |
SQM-0.4L Laboratory Planetary Ball Mill
Samy planetary ball mill is a necessary device for mixing, fine grinding, small sample preparation, new product development and small batch production .Our planetary ball mill is small in size, full in function, high in efficiency and low in noise.
Planetary ball mill is widely used in geology, minerals, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, medicine, environmental protection and other departments.
Product Performance:
Name | Laboratory Planetary Ball Mill |
Model | SQM-0.4L |
Jar Volume | Each jar max 100ml,total volume 400ml |
Feed particle size | Solid material<15mm,Other material <3mm |
Transfer Method | Gear transfer |
Working Method | 2 or 4 ball mill tanks work at the same time |
Maximum charge | 2/3 volume of the grinding jar |
Speed control mode | Frequency conversion speed regulation |
Control system | Frequency conversion control system |
Speed ratio | 2:1(r/min) |
Revolution speed | 5-400 (r/min) |
Rotation speed | 10-800 (r/min) |
Net Weight | 30KG |
Dimension | 48*28*33cm |
Technical Specification:
Model | SQM-0.4L |
Specification | 0.4L |
Available jars specifications | 50-100ml |
Available grinding jars | 2-4pc |
Vacuum grinding jars volume | 50ml |
Grinding jar optional | Zirconia,Agate,Corundum,Nylon,Stainless steel,Polyurethane,Tungest Carbide Alloy,Teflon |
Run set Time | 1-9999 min |
Forward and reverse running time | 1-999 min |
Power Supply | 220V 50HZ |
Total power | 0.26KW |
Noise≤db(A) | <60db |
Detail Images about SQM-0.4L machine:
SQM-0.4L relative grinding jars and balls:
Package for Export:
Certificate about our products:
