TDH-21F Large Capacity High Speed Refrigerated Centrifuge

Mainly applied in a variety of fields such as biochemistry, medical treatment and public health, food safety, life science, forestry, animal husbandry, blood banks, blood stations, biological products and pharmaceutical products. It is the ideal equipment for separation, precipitation, concentration and preparation of samples.

Model:
TDH-21F Large Capacity High Speed Refrigerated Centrifuge
Brand:
Samy
Code:
TDH-21F

Quantity:
Availability:





Inquire Add to Basket

Table top High speed centrifuge Desk type Medical Refrigerated Centrifuge High Speed Refrigerated Centrifuge Laboratory High Speed Centrifuge Laboratory Refrigerated High Speed Centriufuge Large Capacity Refrigerated Centrifuge Laboratory Refrigerated Centrifuge Medical high speed Centrifuge Medical Refrigerated Centrifuge Medical Cool large capacity Centriuge

Product Description

Product Features

1. Microcomputer precise control, high torque AC variable frequency motor drive, long life; digital tube or LCD display, automatic calculation of RCF value.

2. It adopts all-steel structure and special shock absorber to improve the stability of the machine and reduce noise and temperature rise.

3. The program can be edited and stored, and users can adjust it according to their needs.

4. The imported fluorine-free compressor unit is adopted, which has fast cooling and low noise, and can be operated at low temperature according to its needs.

5.Adopt electronic door lock, with functions such as over-speed, unbalance, overload, door cover detection and protection.

6.A variety of different rotors can be selected to meet different fields, (various adapters of 0.5-250ml can be customized)

Technical Parameters

Model	TDH-21F Desk Top High Speed Refrigerated Centrifuge
Max Capacity	4×750ml
Max Speed(r/min)	21000
Max RCF(×g)	29060
Temp.control range	-20℃～+40℃
Timer range	0-99h59min
Total Power	1.8kW
Machine Noise	≤ 60dB
Speed accuracy	±20rpm/min
Weight	96kg

Rotor Specifications

No.	Rotor	Capacity	Max speed	Max RCF	Remarks
No.01	Angle rotor	12×1.5ml	21000rpm	29060xg
No.02	Angle rotor	8×5ml	18000rpm	23180xg
No.03	Angle rotor	24×1.5ml	15000rpm	20620xg
No.04	Angle rotor	12×10ml	14000rpm	18620xg
No.05	Angle rotor	48×1.5ml	14000rpm	20370xg
No.06	Angle rotor	8×15ml	14000rpm	19940xg	Conical bottom
No.07	Angle rotor	6×50ml	13000rpm	17040xg
No.08	Angle rotor	12×15ml	13000r/min	18700xg
No.09	Angle rotor	4×100ml	13000r/min	18130xg
No.10	Angle rotor	6×50ml	12000r/min	15610xg	Conical bottom
No.11	Angle rotor	8×50ml	12000r/min	16740xg
No.12	Swing rotor	6×100ml	4000r/min	2950xg	Round cup
No.13	Swing rotor	64×5/2ml	4000r/min	2950xg
No.14	Swing rotor	4×750ml	4000r/min	2950xg	Round cup
No.15	Swing rotor	96×5/2ml	4000r/min	2950xg
No.16	Micro-plate rotor	2×4×96 well	4000r/min	2100xg
